806-960MHz CDMA GSM Sector Panel Antenna 16dBi 120degrees Horizontal Outdoor High Gain Base Station Antenna

Brand Name : Deertom

Model Number : DT-SPA806-960-16-120

Certification : CE,ROHS,ETC

Place of Origin : CHINA

MOQ : 1piece

Price : $100-$300 per piece

Payment Terms : T/T, Western Union

Supply Ability : 100pcs per day

Delivery Time : 7

Packaging Details : Neutral Package

Frequency : 806-960MHz

Gain : 16dBi

Horizontal Beamwidth : 120degrees

Contact Now

ELECTRICAL
Model DT-SPA806-960-16-120
Frequency Range 806-960MHz
Gain 16dBi
Beamwidth H: 120° , E: 7°
VSWR ≤1.5
F/B Ratio ≥20dB
Polarization Vertical
Max Power 100W
Nominal Impedance 50Ω
Lightning Protection DC Ground
MECHANICAL
Connector N Female or customized
Antenna Dimension 2500*288*141mm
Weight 13kg
Radome Material UPVC
Rated Wind Velocity 60m/s
Connector Position Bottom

806-960MHz CDMA GSM Sector Panel Antenna 16dBi 120degrees Horizontal Outdoor High Gain Base Station Antenna


Wholesale 806-960MHz CDMA GSM Sector Panel Antenna 16dBi 120degrees Horizontal Outdoor High Gain Base Station Antenna from china suppliers

806-960MHz CDMA GSM Sector Panel Antenna 16dBi 120degrees Horizontal Outdoor High Gain Base Station Antenna Images
